15 Ton Electric Battery Industrial Motorized Carts With Loading Table Rail Cart

Product Categories

Henan Perfect Handling Equipment Co., Ltd.

Contact Now

15 Ton Electric Battery Industrial Motorized Carts With Loading Table Rail Cart

Name: 15 Ton Electric Battery Industrial Motorized Carts With Loading Table Rail Cart
Brand: 15 ton electric battery flat car
Price: 3000 USD

Brand Name : 15 ton electric battery flat car

Model Number : 15 ton electric battery flat car

Certification : CE ISO SGS

Place of Origin : China(Mainland)

MOQ : 1 set

Price : USD 3000~8100set

Supply Ability : 100 sets month

Delivery Time : 20 work days after received balance payment

Packaging Details : trap and wooden case

Product Name : 15 ton electric battery flat car

Application : Transfer Materials

Capacity : 1-300T

after-sales Service Provided : Engineers available to service machinery

Running speed : 0-20m/min

Certificates : CE ISO SGS

Dimension : Customized

Contact Now

15 Ton Electric Battery Industrial Motorized Carts With Loading Table Rail Cart

Description of 15 ton electric battery flat car

This 15 ton electric battery flat car is usually used at ship yard, plant and factory, certain production line. The 15 ton electric battery flat car could get power from outside or from the battery. The 25 ton transfer cart was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and/or products through manufacturing facilities.The 15 ton electric battery flat car construction is based on our world renowned die15 ton electric battery flat car and provides controlled movement of heavy and oversized loads such as dies, coils and work in progress. Our 15 ton electric battery flat car is available in a number of configurations specifically designed to suit the needs of our customers.

Site map for customer use

Technical Parameter of 15 ton electric battery flat car

Model		BXC-2t	BXC-20t	BXC-50t	BXC-100t	BXC-150t
Rated Load(t)		2	20	50	100	150
Table Size(mm)	Length(L)	2000	4000	5500	6500	10000
	Width(W)	1500	2200	2500	2800	3000
	Heigth(H)	450	550	650	900	1200
Wheel Base(mm)		1200	2800	4200	4900	7000
Rail Inner Gauge(mm)		1200	1435	1435	2000	2000
Wheel Diameter(mm)		270	350	500	600	600
Wheel Quantity		4	4	4	4	8
Ground Clearance(mm)		50	50	50	75	75
Running Speed(min)		0-25	0-20	0-20	0-20	0-18
Motor Power(kw)		1	2.2	5	10	15
Battery Capacity		180	180	330	440	600
Battery Voltage		24	48	48	72	72
Running time When Full Load		4.32	4	3.3	3.2	2.9
Running Distance for Once Charge(KM)		6.5	4.8	4	3.8	3.2
Reference Weight(t)		2.8	5.9	8	14.6	26.8
Recommended Rail Model		P15	P24	P43	QU100	QU100

Components Of 15 ton electric battery flat car

Processing Line of 15 ton electric battery flat car

15 Ton Electric Battery Industrial Motorized Carts With Loading Table Rail Cart

Functions & Advantages of 15 ton electric battery flat car

Flat deck or fixtures for transporting special payload;
Custom deck configurations may include lift, tilt, or rotate function;
Payload from 1 ton to 300 tons;
Fixed speed or variable speed capabilities;
The 15 ton electric battery flat car can run on the C-form track or S-form track and L-form track;
Running distance of 25 ton transfer cart is unlimited;
With forward or backing driving;
Options for automatic control;
Available safety equipment includes horn, lights, emergency stop, bumpers and detector.

Application Sites of 15 ton electric battery flat car

The 25 ton transfer cart is mainly applied in assembly line(ring production line,loop production line),metallurgy industry(steel lade),warehouse transport,ship industry(maintenance, assemcle,container transport),work piece transport in workshop,lathe transport,steel factory(steel billet,steel plate,steel coil,steel pipe,section steel structure),construction(bridge,simple building,concrete column,)petroleum industry(oil pump,sucker rod and parts),energy(polycrystalline silicon,generator,windmill),chemical industry(electrolytic cell,retort etc),railway(rail maintenance,rail welding,train tractor).

Package of 15 ton electric battery flat car

Our 15 ton electric battery flat car not only have sold across the country, but also exported to US, Germany, Thailand, Netherlands, South Africa, Syria, Turkey, Nepal etc. The 25 ton transfer cart body is packed with tarp, and the wheel and parts of the 25 ton transfer cart will be packed with wooden case. According the table size and quantity, the 25 ton transfer cart would be transported to clients by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on.

Our factory is located in Xinxiang City, Henan province, where the 25 ton transfer cart are manufactured and assembled. Our plant is full service from the mechanical and control engineering to fabrication and machining, we could offer all of those. With the spirit of quality, durability, satisfaction, we have run our plant for over 15 years, and our products have gotten CE, SGS, ISO certificates. With the high quality machine, skilled workers and experience engineers, we will supply the best 15 ton electric battery flat car for you.

Service

Our commitment: The load bearing safety factor of the15 ton electric battery flat car is no less than 120%.
Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
16 hours engineering service and 24 hours internet service for our customers.
During the warranty period, if our 15 ton electric battery flat car can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.

Q & A

1. Q: What is the size and load of this 15 ton electric battery flat car?
A:The size and load of our this 15 ton transfer cart is customized design according to your requirement.
2. Q: How should I operate this 15 ton electric battery flat car ?
A: The 15 ton transfer cart is controlled by pendant & remote radio control. The controller could be push button or joy-sticker.
3. Q: Is there any braking system on this 15 ton electric battery flat car ?
A: Yes, there are electromagnetic brakes on the 25 ton transfer cart. When the 25 ton transfer cart is power off, the brake will work automatically. And there are emergency stop buttons on the remoter and the 25 ton transfer cart, you can push it for emergency stop.
4. Q:What is the warranty period? What kind of service do you offer in the warranty period?
A: The warranty period for our product is 12 months from the time we delivery, during the warranty period, we will send spare parts to you on our own cost if damaged because of bad quality, and we will guide you how to replace it. If necessary, our engineer is available to your factory for maintenance.
5. Q: How do you transport the 25 ton transfer cart and what is the package ?
A: For the big part, we will pack it with tarpaulin and wood pallet on the bottom of the 15 ton transfer cart to prevent it from moving. For the small part, we will pack it in wood case.
6. Q: What is the leading time, delivery term, and payment term ?
A: Usually our leading time is 45 days, for some special 15 ton transfer cart, such as hydraulic lifting 25 ton transfer cart, it maybe longer to 60 days. About the delivery term, we accept EXW, FOB, CIF, DDU. About the payment, we accept T/T or L/C.

Product Tags:

material transfer trolley

industrial motorized carts

15 Ton Electric Battery Industrial Motorized Carts With Loading Table Rail Cart Images
