Customized 1-80 ton battery transfer cart for transport coil and dies

Name: Customized 180 ton battery transfer cart for transport coil and dies
Brand: 1-80 ton battery transfer cart
Price: 3000 USD

Wholesale Customized 1-80 ton battery transfer cart for transport coil and dies from china suppliers

Brand Name : 1-80 ton battery transfer cart

Model Number : 1-80 ton battery transfer cart

Certification : CE ISO SGS

Place of Origin : China(Mainland)

MOQ : 1set

Price : USD 3000~7600 set

Supply Ability : 100 sets month

Delivery Time : 20 work days after received balance payment

Packaging Details : trap and wooden case

Product Name : 1-80 ton battery transfer cart

Capacity : 1-80T

Application : Transfer Materials

Running speed : 0-20m/min

Certificates : CE ISO SGS

Contact Now

Customized 1-80 ton battery transfer cart for transport coil and dies

This 1-80 ton battery transfer cart is usually used at ship yard, plant and factory, certain production line. The industry 1-80 ton battery transfer cart could get power from outside or from the battery. The 1-80 ton battery transfer cart was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and/or products through manufacturing facilities. The 1-80 ton battery transfer cart construction is based on our world renowned battery transfer cart and provides controlled movement of heavy and oversized loads such as dies, coils and work in progress. Our industry battery transfer cart is available in a number of configurations specifically designed to suit the needs of our customers.

Technical Parameter of industry battery transfer cart

Model		BXC-2t	BXC-20t	BXC-50t	BXC-100t	BXC-150t
Rated Load(t)		2	20	50	100	150
Table Size(mm)	Length(L)	2000	4000	5500	6500	10000
	Width(W)	1500	2200	2500	2800	3000
	Heigth(H)	450	550	650	900	1200
Wheel Base(mm)		1200	2800	4200	4900	7000
Rail Inner Gauge(mm)		1200	1435	1435	2000	2000
Wheel Diameter(mm)		270	350	500	600	600
Wheel Quantity		4	4	4	4	8
Ground Clearance(mm)		50	50	50	75	75
Running Speed(min)		0-25	0-20	0-20	0-20	0-18
Motor Power(kw)		1	2.2	5	10	15
Battery Capacity		180	180	330	440	600
Battery Voltage		24	48	48	72	72
Running time When Full Load		4.32	4	3.3	3.2	2.9
Running Distance for Once Charge(KM)		6.5	4.8	4	3.8	3.2
Reference Weight(t)		2.8	5.9	8	14.6	26.8
Recommended Rail Model		P15	P24	P43	QU100	QU100

NOTES:

Flat deck or fixtures for transporting special payload;
Custom deck configurations may include lift, tilt, or rotate function;
Payload from 1 ton to 300 tons;
Fixed speed or variable speed capabilities;
On board charging is available if battery drives;
With forward or backing driving;
Options for automatic control;
Available safety equipment includes horn, lights, emergency stop, bumpers and detector.
